Wireless Data Terminal

:: Wireless Data Terminal ::

:: Introduction

We Specialized in the Design, Development and Manufacturing wide range of Wireless Data Terminals. For over 2 years We developed Wireless Data Terminals that are used successfully in various cross functional applications for Industrial, mobile, remote communications, automation and stands ahead of the competition in innovative race of integrating sophisticated technologies like GSM, GPRS, CDMA, GPS into Wireless.

Wireless Data Terminal (WDT) is another innovation from RaviRaj Technologies. WDT is a sleek, aesthetically crafted Terminal with entrenched features like Built in Printer, Built in Modem ( PSTN / GSM ), Built in Smart card reader.

Spot Billing Smart Ticket Thermal Printer Ewireless phone, wireless plan, wireless network verizon wireless, att wireless, at t wireless, cingular wireless, wireless, , wireless service, sprint wireless, wireless internet, prepaid wireless, wireless speaker, wireless router, liberty wireless, wireless networking, arch wireless, verizon wireless amphitheater, wireless phone service, wireless weather station, verison wireless, wireless phone plan, nextel wireless, wireless camera, qwest wireless, centennial wireless, broadband wireless, cable wireless, verizon wireless phone, wireless microphone, midwest wireless, wireless.



:: Features :: Application



  • Fully User programmable, in high level 'C'

  • 20 Years calendar real time clock (Battery backed)

  • Upto 16 MB Data memory & 512 k program memory

  • User-friendly IDE for rapid development

  • "C" Libraries Available

  • High-Clarity LCD with backlight ( 4 Rows of 20 Characters )

  • Membrane or Elastomeric Keypad

  • 45, 32, 30, 20 or 15 keys, Standard or Custom Keypad layouts

  • Up to 115.2 k bps Communication

  • Very light weight, versatile & affordable.

  • Rugged Cycolac ? ABS case

  • Customized specification

  • One (1) Year Warranty

  • Ticket Issuing

  • Spot Billing / Meter Reading

  • Point of Sale Terminal

  • Stores Inventory

  • Order Processing

  • Field Data Collection









Wireless Data Terminal has immense scope of applications. WDT can be customized as per the necessities of the automation....be it 'on spot' or 'online' or 'off line' requisites. WDT comes with packaged services of mentioned applications on the right.

.....The Terminal can be user programmable using 'C' and PC.

The unit consists of wide range of optional Hardware components like, Custom Key Pad, Display (4x20), 256K Flash (optional 512K), 128K SRAM (optional 512KB or 1MB) Built in 1.7 Ahr NiMH battery, Intelligent & fast Battery Charger, high speed COM port and programming port, high speed Impact Printer (2.7 lines/sec), Analogic V.22 BIS PSTN modem and Smart Card Reader/Writer.

:: Dimensions Box

Height : 305 mm
Width : 105 mm
Depth : 52 mm
Weight : 750 gm

Printer Box

24Col. Alphanumeric
high speed impact printer(2.7 lines/sec)
Paper width 57mm
Dia-70mm, Weight-60gms

:: Others

Clock Speed : 18.5 Mhz
Serial Ports (RS 232) :
i) Standard one port (115K band)
ii) Programming port : available (806 K baud)
Telephone Line Port : RJ Connector with fixed 2900 bps
Real Time Clock : Available with battery backup

:: Environmental Box

Operating Temperature : 0 to50 C
Storage Temperature : -20 C to +70 C
Humidity : 5 - 95% (Non conducing)
EMI / EMC : Compliant

:: Modem Box

GSM Modem

Multi-Band GSM/GPRS, Dual Band EGSM900/800MHZ,
Quad Band GSM850/900/1800/1900MH2,
Compliant with ETSI GSM Phase2+Standerd,
Class4 ( 2 W @ 250 / 900 MHZ )
Class 1 (1 W @ 1800 / 1900 MHZ )

PSTN modem

Data modem formats: V.22 bis 2400 bps. V.22/Bell
212 A 120Dphs,
Security Modem formats,
Caller ID detection & decode,
AT Command Set,
HDLC formatting in H/W, Integrated DAA,
Parallel Handset detection.





















We also provide portable data terminal windows ce terminal headphones, wireless lan, rogers wireless, wireless communication, ringtone for verizon wireless, wireless deal, wireless keyboard, wireless access point, wireless security, wireless headset, wireless mouse, at and t wireless, wireless appliance, t mobile wireless, verizon

 wireless arena, wireless phone services, cincinnati bell wireless, alltel wireless, verizon wireless music center, prepaid wireless phone, wireless technology, at t wireless phone, virgin wireless, wireless modem, bus card pcmcia wireless, wireless usb adapter, rogers t wireless, wireless at t, singular wireless, cricket wireless, wireless security camera, att t wireless, wireless application, wireless internet service, wireless phone company, sierra

 wireless, wireless web cam, verizon wireless cell phone, wireless company, wireless accessory, wireless printer, home wireless network, verizon wireless theater, wireless internet access, a t t wireless, wireless web, wireless email, wireless isp, free ringtone verizon wireless, wireless network card, wireless video, a1 wireless, wireless

 internet provider, wireless intercom, cingular wireless phone, ring tone for verizon wireless, free wireless phone, att wireless phone, wireless card, wireless security system, wireless antenna, verizon wireless plan, wireless access, wireless dog fence, wireless provider, wireless laptop, linksys wireless router, wireless print server, wireless usb Smart Ticket Thermal Printer.

: Order Information                    India - International

Hardware only

 MOQ

 Part number

 Pricing

WDT Intelligent Hand Held Computer for Spot Billing

100

WDT

USD    $250

 Order by E-mail

for orders Send e-mail: sales@ravirajtech.com
with subject: WDT  order

 Order by Fax

Orders By FAX

You may place an order by fax 24 hours a day, 7 days a week. Simply print the form below and fax it to us at:+91-020-24475992
Download Fax Order Form
